| Electrical Specifications | ||||||
| ZTT Product Code | ZRI617-3800HH06i360E | |||||
| Frequency Range | MHz | 617-806 | 806-960 | 1350-1550 | 1710-2700 | 3300-3800 |
| Gain | dBi | 3.5±0.5 | 3.5±0.5 | 3.5±0.5 | 4.5±1.0 | 5.0±1.0 |
| Polarization | Linear Horizontal x2 | |||||
| VSWR | ≤1.8 | ≤1.8 | ≤1.8 | ≤1.8 | ≤1.8 | |
| Isolation | dB | ≥16 | ≥16 | ≥16 | ≥20 | ≥25 |
| PIM, 3rd Order, 2 x 20W | dBc | ≤-153 | ||||
| Input Power, Maximum | watts | 50 | ||||
| Impedance | ohm | 50 | ||||
| Mechanical Specification | ||||||
| Connector Type | 4.3-10-female×2 | |||||
| Size | mm | Φ266×18 | ||||
| Antenna Weight | kg | 0.5 | ||||
| Mounting Kit | Ceiling, via hole (standard) | |||||
| Radome Material and Color | ABS, White, RAL9003 | |||||
| Operational Temperature | °C | -55～85 | ||||
| Operational Humidity | % | < 95 | ||||
