| Item | Specification | |
| Frequency | UL: 380 ~ 385 MHz / DL: 390~ 395 MHz | |
| Bandwidth of Channels | 12.5/25KHz Optional | |
| Number of Channels | 1 ~ 16 | |
| Gain | UL 75dB (MU+RU), DL 80dB (MU+RU) | |
| Output Power | UL 30dBm (MU), DL 36dBm (RU)
| |
| Gain attenuate | 1~25dB, Step of 1dB(MU or RU) | |
| ALC control Range | ≥30 dB | |
| VSWR | ≤ 2 | |
| Spurious | <-13 dBm (2 Carrier ) | |
| Spurious emission | ≤-36dBm @ 9KHz~1GHz, ≤-30dBm @ 1GHz~12.75GHz | |
| ORx / OTx Wavelength | 1310 nm / 1550 nm (WDM) | |
| Noise figure
| ≤9dB (1 Master Unit and 1 Remote) | |
| Time Delay | ≤35 μS @12.5K | |
| Monitoring | Local | USB Local Connection |
| Remote | NMS Cloud Connection | |
| Remote & Local Control | 1.UL&DL Gain |
| 2.Working Frequency | |
| 3.Sub band ON/OFF | |
| 4.Temperature Alarm Level Limit | |
| 5.UL/DL Output Over Power Alarm Level Limit | |
| 6.DL Output Under Power Alarm Level Limit | |
| 7.DL VSWR Alarm Level Limit | |
| 8.Alarm Enable | |
| 9.UL&DL PA ON/OFF | |
| 10.Bandwidth mode | |
| Remote & Local Monitoring | 1.UL&DL Output Power |
| 2.Temperature | |
| 3.Alarms(Over Temp Alarm,AC Power Alarm,Low Battery Alarm,UL/DL Power Alarm,LD/PD Alarm,Door Alarm,VSWR Alarm) | |
| 4.UL&DL PA ON/OFF | |
| 5.Working Frequency | |
| 6.Sub band ON/OFF | |
| 7.Bandwidth Mode | |
| Optical transmit power | -2 ± 2dBm |
| Optical receive sensitivity | ≤-13dBm |
| Optical transmission distance | ≥15 KM |
| optical interface | LC/LC or FC/FC |
| I/O Impedance | 50Ω |
| RF Port Connectors | N-Female |
| Humidity | <90% |
| Operating Temperature
| -10℃ ~ +55℃ |
| Power supply | AC 110/220V, 50/63Hz or DC 48V |
| Power consumption | ≤80W@ MU ≤100W@ RU |
| Dimension | 370×332×137 mm@ MU 370×332×137 mm@ RU |
| Weight | ≤15 kg @ MU ≤15 kg @ RU |
