| Item | Uplink | Downlink | |
| Frequency | Band 1 | 1920 ~ 1940 MHz | 2110 ~ 2130MHz |
| Band 3 | 1735.3 ~ 1754.7 MHz | 1830.3 ~ 1849.7 MHz | |
| NR 78 | 3600 ~ 3700 MHz | 3600 ~ 3700 MHz | |
| Gain | Band 1, 3 | 75±3 dB | 80±3 dB |
| NR 78 | 80±3 dB | 80±3 dB | |
| Output power | Band 1, 3 | 20±2 dBm | 27±2 dBm |
| NR 78 | 23±2 dBm | 30±2 dBm | |
| VSWR | ≤2 dB | ≤2 dB | |
| Manual gain control range | 1~31 dB , Step of 1 dB | 1~31 dB , Step of 1 dB | |
| Automatic gain control rang | ≥50 dB | ≥50 dB | |
| Max input power without damage | -10 dBm | -10 dBm | |
| Spurious Emission | 9KHz~1GHz | ≤-36 dBm | ≤-36 dBm |
| 1GHz~12.75GHz | ≤-30 dBm | ≤-30 dBm | |
| ACLR | BWchannel | ≥35 dB | ≥38 dB |
| 2×BWchannel | ≥40 dB | ≥45 dB | |
| Error vector magnitude (EVM) | LTE≤8% RMS, NR≤3.5% RMS | ||
| Noise figure | ≤8 dB | ||
| Time delay | ≤1 us | ||
| TDD synchronization | Adaptive synchronization | ||
| Repeater Type | Analogue | ||
| Power supply | AC 90 ~264V 50/63Hz | ||
| Power consumption | ≤120 W | ||
| RF connector | N-Female | ||
| Protect grade | IP40 | ||
| Environment temperature | -10℃ ~ 55℃ | ||
| Environment humidity | ≤95% | ||
| Size | 360*268*120mm | ||
| Weight | <8.5 kg | ||
