- Good processability. - Excellent flame retardancy, suitable for drop-wire cable outer sheath: single vertical burning ≥ 90%, smoke density ≥ 50%. - Low smoke, halogen-free, meeting environmental and safety requirements.
Test Items | Unit | Typical Value | Test Standard | Equivalent Standard |
Product Color | — | Black | / | / |
Density | g/cm³ | 1.52 | GB/T 1033.1 | ISO 1183-1 |
Tensile Strength | MPa | 12.14 | GB/T 1040.3 | ISO 527-3 |
Elongation at Break | % | 172.77 | GB/T 1040.3 | ISO 527-3 |
Thermal Aging (100℃, 168h) — Tensile Strength | MPa | 13.72 | GB/T 2951.12 GB/T 1040.3 | IEC 60811-1-2 ISO 527-3 |
Thermal Aging (100℃, 168h) — Elongation at Break | % | 160.46 | ||
Thermal Aging (100℃, 168h) — Rate of Change of Tensile Strength | % | 13.01 | ||
Thermal Aging (100℃, 168h) — Rate of Change of Elongation at Break | % | -7.12 | ||
Volume Resistivity (20℃) | Ω·cm | 1.4×10¹¹ | GB/T 1410 | IEC 60093 |
Dielectric Strength | MV/m | 19 | GB/T 1408.1 | IEC 60243-1 |
Low-Temperature Embrittlement (-25℃) ≤15/30 | — | Pass | GB/T 5470 | ISO 974 |
pH Value | — | 5.3 | GB/T 17650.2 | IEC 60754-2 |
Conductivity | μs/mm | 2.4 | GB/T 17650.2 | IEC 60754-2 |
Halogen Acid Gas Content | mg/g | 1.1 | GB/T 17650.1 | IEC 60754-1 |
Resistance to Environmental Stress Cracking (1) F₀/h | — | Pass | GB/T 2951.41 | IEC 60811-4-1 |
This product is a low-smoke halogen-free flame retardant polyolefin sheathing compound, primarily suitable for the following applications: Outer sheath of drop-wire (butterfly) cables, meeting single vertical burning (≥ 90%) and smoke density (≥ 50%) requirements.Please provide the following details to help our sales representatives better understand your needs and get In touch with you as soon as possible.
